Generally, companies software are built in a three part system: a client side/user interface, a database, and a side-server application called a monolith. Monoliths are often built as a single logical executable, in a single-tiered with multiple layers: presentation, business logic, and data-access. These apps are easy to design and develop, though they are difficult to maintain and make evolve, which makes them technologically locked-in and unadapted for the Cloud. To follow the evolution of Cloud Computing and Service-Oriented Architecture (SOA), microservices (MS) have naturally emerged as the next trend due to the advantages they provide. These advantages include increased maintainability, better scalability, and an overall better synergy with DevOps techniques. This makes migrating legacy software towards a microservice-oriented architecture (MSA) an attractive prospect for organizations.
What are microservices?
Microservice-oriented architecture is an architecture-style to develop a single application as a suite of small services, each running in its own process and communicating with lightweight mechanisms (HTTP resource, API). These services are built around business capabilities and are independently deployable by fully automated deployment machinery. There is a bare minimum of centralized management of these services, which may be written in different programming languages and use different data storage technologies.
MSAs can be more complex to organize and may increase technological requirements and network use, though, it shows high technological adaptability, modularity, high scalability, reusability, and can be independently developed by small teams.
Microservices architecture are more complex to organized and increased technological requirements and network use, though, it shows high technological adaptability, modularity and loose coupling, it’s highly scalable, reusable and can be independently developed in small team.
How do we move towards microservices?
Monolithic application to microservices migration architecture can be divided into two steps.
The first step is to identify a microservice-oriented architecture from the monolith’s source code. Its main goal is to extract the target application architecture to help architects modernize their application.
The second step is to transform the existing source code to one implementing the identified MSA. That’s the materialization.
Recovery phase: Layered identification approach
This first step consists in identifying and reorganizing the monolith’s functionalities into classes to propose a set of microservice candidates to guide the transformation phase. However, not all classes are equal, some are structural and some are data-oriented. We propose an identification approach that takes both roles into consideration.
The layered identification approach leverages well-established design patterns and anti-patterns to guide the process of identifying microservices. Our approach takes in consideration these design patterns and anti-patterns and proposes an identification process in three steps:
- Recover the OO artifacts from the OO source.
- Categorized the OO artifacts in different layers of the architecture (presentation, business and data-access).
- From the extracted internally layered architecture’s artifacts, the microservice candidates are identified through an automatic clustering approach.
We analyze the monolith’s presentation layer to determine the endpoint of each business functionality, then we apply a vertical decomposition to these endpoints in order to find the necessary classes to implement each feature as a microservice. In this process, we also define a bounded context of the data-access layer for each microservice.
Recovering the layered architecture by reverse-engineering
To identify microservice candidates, we have to extract the layered architecture artifacts from the existing code of the monolithic application. It involves identifying its structural elements and the relationship between them by analyzing the existing source code. From these artifacts, the layered architecture can be revealed through reverse-engineering techniques. To facilitate the labeling process and to represent the extracted layered architecture, we propose the Layered Architecture Metamodel (LAMM) presented in the figure below.
This metamodel can be divided in three viewpoints:
- Layered Architecture: responsible for representing the typical 3 Layers architecture (presentation, business-logic and data access).
- DI/IoC: responsible for representing the decoupling mechanism to create high-cohesive layer artifacts.
- Data Persistence: responsible for representing the various data types found in web applications.
A semi-automatic process is applied to place the application’s classes into one of these three by mapping them to one of the LAMM entities. Once we’ve mapped the classes into the appropriate entity, we analyze the dependencies to their layer counterparts. Once all entities and their relationship have been mapped to the LAMM model, the microservice identification step begins.
Microservice identification process using extracted artifacts
We use a hierarchical clustering algorithm to create a dendrogram which is cut following a depth-first algorithm and presented to the user for validation.
To guide the clustering, we combine two similarity measures. The first measure calculates the structural cohesion between the classes of a microservice candidate and produce a similarity which promotes structural cohesion by rewarding clusters in which there are more internal relationships. When applied on our LAMM model, it will ideally propose decomposition that favors vertical microservices focused on business capabilities and limit the risk of creating wrong cuts. The second measure calculate the data cohesion of a microservice candidate to encourage clusters with classes that manipulate the same class and promote clusters who are data autonomous. When applied to a clustering algorithm it will ideally propose a decomposition that favors grouping classes manipulating the same data and limit the risk of creating Shared Persistence between microservice by creating data ownership.
The main contribution of this model-driven approach is the identification of microservices from the original source code. The proposed approach leverages the internal layered architecture of monolithic applications while providing a visualization tool to assist experts in the identification validation.
The internal architecture is often detailed in the code source through class annotations, namespaces, and configuration files. The proposed approach uses the layered architecture to vertically decompose a monolith while minimizing the coupling between microservices. Particularly, we were able to demonstrate that adding artifacts about the layered architecture of the monolithic application had a positive impact on the identification process.
In future works, we intend to extend our identification approach to integrate refactoring, packaging, and deployment of the identified MSA. To further strengthen our validation, we intend to use this end-to-end migration approach to generate and evaluate the quality of our MSA at runtime.
